SERIES: SNT-DOCK-LASER
PILOT READY
Target Safety Problems
Loading Dock Area Visibility
Truck Docking Alignment Risk
Industrial Projection Hardware
Laser Truck Docking Guidance System
Laser-based truck docking guidance system for projecting visible alignment lines in loading-dock and vehicle-positioning applications.
Power Output
Laser guidance configuration; final output/class to verify
Input Voltage
9-80V
Typical Height
3.0 - 12.0 m
Protection
IP65 Rated
Application Engineering Note
Projection visibility is determined by mounting height, ambient lux, lens optic selection, and floor reflectivity. SNT provides exact Gobo pattern sizing and optical validation prior to pilot deployment.
Engineering Parameters
Technical Specifications & Optical Sizing
All measurements verified at 25°C ambient conditions.
Standard Parameters Verified Values
- Rated Output
- 1200mw
- Operating Voltage
- 9-80V
- Light Source
- Green laser diode reference option
- Power / Output
- Laser guidance configuration; final output/class to verify
- Input Voltage
- Project-specific power supply
- Recommended Installation Height
- Dock / structure mounted; final height based on dock geometry
- Environmental Protection
- IP65 reference target; verify final SNT enclosure
- Control Mode
- Always-on / dock-door / sensor / relay trigger
- Data Status
- Draft reference configuration — verify against final SNT datasheet before publishing
Environmental & Compliance Industrial Grade
- Ingress Protection
- IP65 (Dust-tight & Water Jet Protected)
- Operating Temperature
- -20°C to +50°C
- Housing Material
- Die-cast Aluminum Alloy 6063
- Optical Glass
- High-Transmittance Coated Quartz Lens
Detailed Description & Functional Overview
Laser-based truck docking guidance system for projecting visible alignment lines in loading-dock and vehicle-positioning applications.
Typical Applications
This product series is intended for industrial visual safety projects where configuration must be matched to actual site conditions.Reference Configuration
- Light / Signal Source: Green laser diode reference option
- Power / Output: Laser guidance configuration; final output/class to verify
- Input Voltage: Project-specific power supply
- Recommended Installation Height: Dock / structure mounted; final height based on dock geometry
- Environmental Protection: IP65 reference target; verify final SNT enclosure
- Control: Always-on / dock-door / sensor / relay trigger
Lens / Optical Configuration
- Line Guidance Optic: Dock-specific — Visible guide line. Reference architecture inspired by industrial laser docking systems; verify final SNT optic.
- Alignment Line Optic: Dock-specific — Project-specific line length. For truck/trailer alignment guidance.
Selection Information Required
Please provide the application, mounting height, projection/detection distance, ambient light, required marking or detection area, floor/environment conditions, trigger logic and project quantity before final configuration. Draft website data: reference specifications must be verified against the final SNT datasheet before publication or quotation.
Application Sizing & Pilot Request
Configure this system for your facility.
SNT recommends projection models based on your exact ceiling height, ambient lux, floor surface, and safety message requirement. Submit your data for an application review.
Pilot Validation Process
- 01. Parameter evaluation & optical simulation
- 02. Tailored pilot unit shipment with chosen gobo
- 03. On-site visibility test & pilot pass decision
- 04. Standardized bulk deployment & replication
