Solution
SERIES: SNT-CRANE-LINE
PILOT READY
Target Safety Problems
Crane Hazard Zone Visibility
Hazard & Restricted Area Visibility
Suspended Load Position Awareness
Industrial Projection Hardware
Crane LED Line Warning Light Series
Crane-mounted LED warning line series for dynamically visualizing hazard boundaries beneath overhead cranes and suspended loads.
Power Output
300–400W reference configurations; confirm SNT production model
Input Voltage
9-80V
Typical Height
3-10M
Protection
IP65 Rated
Application Engineering Note
Projection visibility is determined by mounting height, ambient lux, lens optic selection, and floor reflectivity. SNT provides exact Gobo pattern sizing and optical validation prior to pilot deployment.
Engineering Parameters
Technical Specifications & Optical Sizing
All measurements verified at 25°C ambient conditions.
Standard Parameters Verified Values
- Rated Output
- 1200MW
- Operating Voltage
- 9-80V
- Optimum Projection Distance
- 3-10M
- Standard Lens Angle
- 30°/45°/60°/90°/110°
- Light Source
- High-power LED with line-forming optic
- Power / Output
- 300–400W reference configurations; confirm SNT production model
- Input Voltage
- AC 100–240V, 50/60Hz (verify final model)
- Recommended Installation Height
- 5–12 m typical LED crane-line application range
- Environmental Protection
- Industrial dust/humidity-resistant enclosure; exact IP to verify
- Control Mode
- Crane power / relay / PLC / optional motion-linked activation
- Data Status
- Draft reference configuration — verify against final SNT datasheet before publishing
Environmental & Compliance Industrial Grade
- Ingress Protection
- IP65 (Dust-tight & Water Jet Protected)
- Operating Temperature
- -20°C to +50°C
- Housing Material
- Die-cast Aluminum Alloy 6063
- Optical Glass
- High-Transmittance Coated Quartz Lens
- IP Rating
- 65
Detailed Description & Functional Overview
Crane-mounted LED warning line series for dynamically visualizing hazard boundaries beneath overhead cranes and suspended loads.
Typical Applications
This product series is intended for industrial visual safety projects where configuration must be matched to actual site conditions.Reference Configuration
- Light / Signal Source: High-power LED with line-forming optic
- Power / Output: 300–400W reference configurations; confirm SNT production model
- Input Voltage: AC 100–240V, 50/60Hz (verify final model)
- Recommended Installation Height: 5–12 m typical LED crane-line application range
- Environmental Protection: Industrial dust/humidity-resistant enclosure; exact IP to verify
- Control: Crane power / relay / PLC / optional motion-linked activation
Lens / Optical Configuration
- Narrow Crane Line Optic: 6–12 m — Project-specific line length/width. For higher mounting positions.
- Standard Crane Line Optic: 5–10 m — Project-specific. General overhead crane boundary marking.
- Wide Crane Line Optic: 4–8 m — Project-specific. For wider hazard-zone visualization.
Selection Information Required
Please provide the application, mounting height, projection/detection distance, ambient light, required marking or detection area, floor/environment conditions, trigger logic and project quantity before final configuration. Draft website data: reference specifications must be verified against the final SNT datasheet before publication or quotation.
System Integration
Compatible Safety Solutions
Application Sizing & Pilot Request
Configure this system for your facility.
SNT recommends projection models based on your exact ceiling height, ambient lux, floor surface, and safety message requirement. Submit your data for an application review.
Pilot Validation Process
- 01. Parameter evaluation & optical simulation
- 02. Tailored pilot unit shipment with chosen gobo
- 03. On-site visibility test & pilot pass decision
- 04. Standardized bulk deployment & replication
